Q13 Series Pipe Threading Lathe Metal Fabrication

Product Overview

For decades, HQ Machine Tool’s universal conventional pipe threading lathe has been the reliable backbone of precision threaded component machining for global metalworking manufacturers. As a core heavy-duty metal fabrication tool, it delivers exceptional control and versatility, ideal for facilities requiring consistent precision and long-term stability.

Built with a robust, vibration-dampening cast iron/steel frame, it ensures durability and minimizes operational vibration—critical for micron-level threading accuracy during high-load machining. Equipped with a multi-speed spindle and precision-aligned tool post, it forms consistent, specification-compliant threads efficiently.

The user-friendly control system suits operators of all experience levels, featuring precision manual handwheels and an intuitive gear change mechanism. It eliminates complex programming and reduces training costs for industrial facilities.

Key Features & Customer Benefits

High Precision Threading For Tight Tolerance Industrial Applications

Our lathe delivers ultra-high precision threading via coaxial spindle-tool post alignment and smooth carriage movement, making it ideal for automotive, aerospace, and medical components requiring strict tolerances.

It supports metric (1-30mm), imperial (28-1 T.PI), and custom threads. Operators adjust pitch easily via the gear change mechanism, enabling flexible production without extra equipment.

Versatile All-In-One Machining Capabilities For Streamlined Production

Beyond threading, it performs turning, facing, boring, and grooving—reducing clamping errors, production time, and costs by completing multiple steps in one setup.

The 4-position manual tool post accommodates various cutting tools (45×45mm shank), enhancing versatility for diverse production needs.

Durable & Reliable Heavy Duty Construction For Long-Term Stable Performance

Our lathes feature a heavy-duty cast iron/steel frame for exceptional rigidity, maintaining precision and performance even after years of 24/7 operation.

High-quality core components (spindle bearings, lead screws, gears) ensure smooth, low-noise operation. Routine maintenance is simple, minimizing unplanned downtime.

Ergonomic Manual Control For Precision Prototyping & Small Batch Production

Precision handwheels enable micron-level tool adjustments, ideal for custom prototyping and small-batch production requiring frequent tweaks.

Ergonomic design places handwheels and levers for easy access, reducing operator fatigue and improving machining accuracy.

Full Technical Specifications

Industrial Applications

Conventional Pipe Threading Lathe For Automotive Industry

Automotive manufacturing requires threaded components that withstand stress and vibration. Our lathes produce high-strength bolts, nuts, and studs for engines, chassis, and transmissions, ensuring perfect fit and durability.

We also manufacture threaded shafts and spindles, with tight tolerances ensuring smooth operation and extended part life.

Aerospace Grade Pipe Threading Lathe For Aerospace Industry

The aerospace sector demands strict precision. Our lathes produce threaded components for aircraft engines, landing gear, and avionics, meeting rigorous safety and performance standards.

We support specialized parts (turbine shafts, engine mounts) with custom threads, ideal for small-batch, zero-error aerospace production.

High Precision Threading Lathe For Medical Device Manufacturing

Medical device manufacturing requires absolute precision. Our lathes produce threaded components for surgical instruments and implants, ensuring functionality and patient safety.

We manufacture orthopedic implants (screws, rods) with micron-level accuracy, ensuring perfect fit and optimal healing.

Pipe Threading Lathe For General Machinery & Equipment Manufacturing

Our lathes are core tools for general machinery, delivering reliable threading for pumps, valves, motors, and industrial equipment.

All-in-one machining streamlines workflows, reducing lead times by completing multiple operations in one setup.

Why Choose Us

Decades of Specialized Expertise In Industrial Machine Tool Manufacturing

With decades of experience, HQ Machine Tool’s time-tested lathes are trusted globally. Backed by a technical team with over 20 years of experience, we provide one-on-one guidance and custom solutions.

Fully Customizable Machine Solutions For Your Unique Production Demands

We offer full customization (bed length, spindle bore, threading range, etc.) to match your unique workpiece and production needs, with no compromise on performance.

Strict Full-Process Quality Control For Consistent Long-Term Performance

Every lathe undergoes rigorous quality control—from raw materials to final calibration—ensuring it meets design specifications and delivers consistent performance.

Full Lifecycle After-Sales Service & Technical Support

We provide comprehensive after-sales support: installation, training, maintenance guidance, spare parts, and 24/7 troubleshooting to minimize downtime.

Factory Direct Pricing & Flexible Order Options

As an OEM, we offer factory-direct pricing with no middleman markup. We support single or bulk orders, with custom quotes and no hidden fees.

FAQ

What is a conventional pipe threading lathe used for?

It’s a heavy-duty tool for precision threading of metal pipes/workpieces, plus turning, facing, boring, and grooving. Used in automotive, aerospace, medical, and general machinery industries.

What pipe threading range do your conventional lathes support?

5 standard models (Q1327-Q1350) cover 130mm-510mm. We can customize the range to your needs.

Can you customize the bed length of your pipe threading lathe?

Yes. Standard center distance is 1500mm-3000mm, adjustable to fit your maximum workpiece length.
