IT6 Slant Bed CNC Lathe Shaft Machining

The CKY series slant bed CNC lathe is a line of metalworking machines designed for processing shaft parts, disc components, and workpieces with complex curved surfaces. Available in five base models — CKY6156, CKY6163, CKY6180, CKY61100, and CKY61125 — this series covers a swing diameter range from 560 mm to 1250 mm, accommodating a broad spectrum of workpiece sizes. The lathe employs a CNC control system paired with a slanted bed structure to support turning operations on various rotational parts. Manufactured by Shandong HQ Precision Technology Co., Ltd., a company established in 1952 and a former designated pipe thread lathe manufacturer for the Ministry of National Machinery Industry, these lathes are produced in a facility holding ISO9001 certification with an annual output of 1,000 units. The company holds 30 patents, including 6 invention patents, and allocates over 5% of annual revenue to research and development.

Key Construction Features of Slant Bed CNC Lathes

Bed and Guideway System

The lathe features a one-piece slant bed cast from high-strength iron, which contributes to structural rigidity and vibration damping during cutting operations. The guideways undergo ultrasonic frequency quenching to enhance surface hardness and wear resistance. Carriage and guideway contact surfaces incorporate Turcite B material to support consistent positioning accuracy over extended operation periods. The slant bed angle is 45 degrees for models CKY6156 through CKY61100, and 60 degrees for the CKY61125, a configuration that facilitates gravity-assisted chip evacuation.

Spindle System

The spindle bore ranges from 80 mm (CKY6156) to 120 mm (CKY61125), with spindle nose configurations from A2-8 up to A2-15. Spindle speed is stepless across all models, with maximum speed decreasing from 1500 rpm (CKY6156) to 630 rpm (CKY61125) as swing diameter increases. Main spindle motor power ranges from 15 kW to 37 kW, scaled to match each model's material removal capacity and torque requirements. Hydraulic chuck sizes range from 12 inches to 32 inches across the series.

Turret and Feed System

Models are equipped with a hydraulic turret offering 12 tool positions, enabling multiple machining operations without manual tool changes. Tool shank size measures 25×25 mm for the CKY6156 and 32×32 mm for larger models. X-axis rapid traverse rate reaches 12,000 mm/min for CKY6156 through CKY6180, and 10,000 mm/min for CKY61100 and CKY61125, all with hard guideways. Z-axis rapid traverse follows the same pattern. Minimum programmable increment for both X and Z axes is 0.001 mm.

Tailstock

The tailstock quill diameter ranges from φ110/120 mm to φ130 mm across the series. Quill taper specifications range from MT5 to MT8, with travel distances from 100 mm to 150 mm depending on the model. The tailstock provides support for long workpieces during turning operations.

Technical Specifications for CKY Series Slant Bed CNC Lathes

Standard and Optional Configurations for CKY Lathes

Standard configuration includes a Siemens CNC controller, NC turret, automatic lubrication system, and coolant pump. Optional configurations allow business buyers to select Fanuc or other brand CNC controllers, hydraulic or power turret variants, and hydraulic tailstock systems. This configurability enables commercial users to match the machine to specific production requirements and existing shop floor control standards.

Industrial Applications of Slant Bed CNC Lathes

CKY series slant bed CNC lathes serve enterprises across multiple sectors. In automotive manufacturing, they process transmission shafts, brake discs, and engine components. Aerospace operations use them for precision turning of alloy parts. The machines also support production in general mechanical processing, hydraulic component manufacturing, and electronics industries. The range of available sizes allows facilities to select a model matched to their typical workpiece dimensions and production volume.

FAQ About Slant Bed CNC Lathes

What swing diameter range do CKY series slant bed CNC lathes support?

The CKY series offers five models with swing-over-bed diameters ranging from 560 mm (CKY6156) to 1250 mm (CKY61125). This range covers small to large workpiece requirements for industrial applications.

Which CNC control systems are compatible with CKY series lathes?

Siemens controller comes as standard. Buyers may optionally select Fanuc or other CNC control system brands to align with their existing equipment and operator familiarity.

What is the machining accuracy of CKY series slant bed CNC lathes?

All models achieve IT6 grade precision for external circle machining and 0.8 μm surface roughness in finish turning operations.

Can the distance between centers be customized?

The CKY series offers multiple center distance options per model, ranging from 750 mm up to 3000 mm. For specific requirements, buyers can discuss customization with the manufacturer.

What after-sales support is available for CKY series lathes?

The manufacturer provides 365/24 online support and on-site after-sales service delivered by a professional engineering team.
