Product Introduction
This series of heavy-duty engine lathes is primarily designed for comprehensive turning operations, capable of machining end faces, outer diameters, inner bores, as well as a wide range of threads including metric, imperial, module, and diametral pitch threads.
Versatile Machining Functions
Taper Turning: Short tapers can be machined independently using the upper tool post. Long tapers are achieved by synchronizing the upper tool post with longitudinal feed.
Additional Operations: Drilling, boring, and trepanning (core drilling) for internal machining.
High Power & Rigidity: Optimized for heavy-duty cutting with high torque and stability.
Wide Speed Range: Supports both low-speed roughing and high-speed finishing.
Hardened Guideways: Ensures precision under heavy loads.
Carbide Tool Ready: Enables aggressive machining of ferrous (e.g., steel, cast iron) and non-ferrous metals (e.g., brass, aluminum).
Custom Threading: Supports specialized threads for gears, pipelines, and hydraulic components.
Typical Applications
Large Shafts & Rotors: For energy, shipbuilding, and heavy machinery.
Flanges & Bushings: High-tolerance parts in oilfield equipment.
Threaded Components: Screws, leadscrews, and couplings.
Technical Advantages
Rigid Construction: Minimizes vibration during deep-cut or interrupted cutting.
User-Friendly: Optional CNC upgrades for complex profiles.
Durability: Designed for continuous industrial use with low maintenance.
ITEM | SPECIFICATION | UNIT | CW61140H/1 | CW61160H/1 |
Capacity | Swing over bed | mm | φ1500 | φ1700 |
Swing over cross slide | mm | φ1050 | φ1250 | |
Distance between centers | mm | 3000-10000 | 3000-10000 | |
Guideway width | mm | 1100 | 1100 | |
Max,load capacity | T | 20 | 20 | |
Spindle | Spindle bore | mm | φ130 | φ130 |
Spindle bore taper | Metric140 | Metric140 | ||
Spindle nose type | 1:30 Extended spindle head | 1:30 Extended spindle head | ||
Spindle speed steps | VF.4 steps | VF.4 steps | ||
Spindle speed range | r/min | 2-37rpm, 23-70rpm 37-110rpm, 70-200rpm | 2-37rpm, 23-70rpm 37-110rpm, 70-200rpm | |
Spindle front bearing | mm | 240 | 240 | |
Chuck | mm | φ1250 | φ1250 | |
Turret | Turret/tool post | Manual turret 4 position | Manual turret 4position | |
Tool shank size | mm | 45×45 | 45×45 | |
Feed | X axis travel | mm | 750 | 750 |
Z axis travel | mm | 2850-985056φ/0.1-12mm | 2850-985056φ/0.1-12mm | |
X axis feed grade/range | 56φ/0.05-6mm | 56φ/0.05-6mm | ||
Z axis feed grade/range | 1870 | 1870 | ||
X axis rapid traverse | mm/min | 3740 | 3740 | |
Z axis rapid traverse | mm/min | 44φ/1-120mm | 44φ/1-120mm | |
Metric thread grade/range | 31φ/28-3/8 | 31φ/28-3/8 | ||
Inch thread grade/range | φ260 | φ260 | ||
Tailstock | Tailstock quill diameter | Mm | Metric 80 | Metric 80 |
Tailstock quill taper | 300 | 300 | ||
Tailstock quill travel | mm | 37 | 37 | |
Motor | Main spindle motor | KW | 1.5 | 15 |
Rapid traverse motor | KW | 2250×2050 | 2250×2150 | |
Dimension | Width x Height | mm | 7700-14700 | 7700-14700 |
Length | mm | 19760 | 20400 | |
Weight | Net weight (3m) | kg | Increase by 1050Kg for every additional 1m | Increase by 1050Kg for every additional 1m |
Please note: Bed length can be customized according to real demands. | ||||
